Description

The Curtain Outdoor Jeweler is a motion detector designed to provide perimeter coverage with exceptional accuracy and almost zero false alarms. Featuring a unique optical system, the device monitors narrow zones up to 12 meters in length. The dual motion detection technology, utilizing two PIR sensors and a Ka-band microwave sensor, filters out false alarms caused by thermal noise, animals, or plants. Detection range and pet immunity are adjustable via a slider on the detector’s casing, while sensitivity settings are configured through AJAX applications to meet the site’s specific needs. The pre-installed batteries ensure stable performance for up to three years.

• Sensor: Two PIR sensors
• Detection angle: 85° Vertical – 5° Horizontal
• Communication protocol: Jeweller (868.0–868.6 MHz)
• Maximum detector-to-Hub distance: Up to 1,700 m (in open space)
• Recommended installation height: 2.4 m
• Temperature sensor: Available
• Power supply: CR123A battery
• Operating temperature: From -25°C to +60°C
• Operating humidity: Less than 95%
• Dimensiosn: 141x60x72 mm
• IP55
